Ruian Film Extruder Machine Manufacturer

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Film
Plastic Processed:
PE
Blow Moulding Type:
Extrusion Blow Moulding
Automatic:
Yes
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Xinshun
Model Number:
SJ-A45 SJ-A50 SJ-A55 SJ-A60
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
film blowing machine will be packed by standard export packaing
Port
NINGBO
Lead Time :
film blowing machine will be shipped in 20days

       Ruian Film Extruder Machine Manufacturer

      High and low-density Film Blowing Machine






1111



                SJ Series HDPE / LDPE Film Blowing Machine

 USE

SJ Series PE Plastic Film Blowing Machine can produce differnt width PE in different thickness with good performance.



FEATURE

1.The main motor adopts frequency control of motor speed to improve the speed regulating stability of main motor and save electricity.

2.The screw and material barrel adopt 38 CRMOALA which has been nitrogen treated

3.The traction frame adopts lifting type. No matter what size the film is, big or small, it can achieve the best effect of cooling.

Main technical parameters:

Model
SJ-50
SJ-55
SJ-60
SJ-65
Screw diameter
50mm
55mm
60mm
65mm
Screw ratio
L/D28:1
L/D28:1
L/D28:1
L/D28:1
Screw speed
10-100r/min
10-100r/min
10-100r/min
10-100r/min
Main output
25-35kg/h
35-50kg/h
55-65kg/h
55-70kg/h
Main motor power
7.5-11kw
11-15kw
15-18.5kw
18.5-22kw
Die head specifixcation
60-120mm
100-170mm
100-170mm
120-220mm
Die head rotational mode
Continuous rotation
Continuous rotation
Continuous rotation
Continuous rotation
Film single-layer thickness
0.01-0.10mm
0.01-0.10mm
0.01-0.10mm
0.02-0.10mm
Film max.folding width
600mm
800mm
1000mm
1100mm
Total powder
22kw
26kw
30kw
42kw
Machine weight
2000kg
2300kg
2000kg
3800kg
Overall dimensions
4500×1800
×3500mm
5500×2000
×3800mm
6000×2200
×4200mm
6000×2400
×4300mm
